DI-209
|
SPARK PLUG
WIRE SEPARATOR (white plastic
retainer that clips to metal brackets at various points at front
lower heads & thermostat housing bolt) - Big Blocks
|
$
7.95 ea.
|
|
|
DI-481
|
SPARK PLUG
WIRE SEPARATOR - All engines (universal
black plastic; 4 groove)
|
$ 4.95 ea.
|
|
|
DI-480
|
SPARK PLUG
WIRE SEPARATOR - Small Block (fits
on valve cover; 4 groove; need 2)
|
$
9.95 ea.
|
|
|
DI-479
|
SPARK PLUG
WIRE SEPARATOR - Small Block (fits
on valve cover; 2 groove; need 2)
|
$
9.95 ea.
|
|
|
EG-6785
|
SPARK PLUG
WIRE SEPARATOR - 65-69 Big Block (mounts
to front left hand corner of engine)
|
$ 59.95 pr
|
|
|
EG-6786
|
SPARK PLUG
WIRE SEPARATOR - 66-69 426 Hemi (mounts
at the front left corner of engine and near the coil strap; for cars
using round air cleaners)
|
$
59.95
|
|
|
DI-301
|
VALVE COVER
GROMMET - Used on 273, Big Block & Hemi engines
(round,
white plastic, insulates the ignition wires from valve covers or
wire routing brackets)
|
$
4.95 ea.
|
|
|
EG-1157EL
|
426 Hemi #7
cylinder FLEXIBLE SPARK PLUG BOOT (this
is the flexible long rubber boot for the spark plug end of the #7
cylinder; approx. 4-1/2" lg. All other cylinders take the hard
plastic version which is non-flexible)
|
$ 34.95 ea.
|
|
|
FW-395R
|
SPARK PLUG
WIRE RETAINER - 66-68 A, B & C Body Small Block 2 & 4 Barrel
(holds two wires on top of the
valve covers; snaps into metal tabs; natural nylon)
|
$
9.95 ea.
|
|
|
FW-196S
|
Spark Plug
Tube Rubber O RINGS (set of 8) - All 426 Hemi engines
|
$
29.95/set
|
|
HF-R2
|
IGNITION WIRE BRACKET - 1967-69 A
Body Big Block (correct gauge
and thermo plastic coated as original; located on left front exhaust
manifold stud w/ "L" bracket; holds plug wires #1, #3
& #5)
|
$ 18.95 ea.
|
62-65
IGNITION WIRE BRACKETS
|
 |
HF-Q2 |
IGNITION WIRE BRACKET - 1962-65 Big Block
(bolts to the left thermostat housing bolt & holds all left side
wires) |
$ 29.95 |
 |
HF-G2 |
IGNITION WIRE BRACKET - 1962-65 Big Block
(bolts to both the left & right side front exhaust manifold studs to
hold all wires on each respective side) |
$ 24.95 |
66-67
IGNITION WIRE BRACKETS
Brackets are correct gauge steel & rubber dipped where
applicable. Brackets may require minor bending or fitting to route
wires correctly. Brackets should be attached to, and painted with
engine.
|
|
|
HF-J
|
#8 CYLINDER
IGNITION WIRE BRACKET - All Big Blocks (bolts
to right rear exhaust manifold stud;
1 required)
|
$
14.95 ea.
|
|
|
HF-K
|
#7 CYLINDER
IGNITION WIRE BRACKET - Big Block C Body & applications where #7
cylinder ignition wire runs over valve cover
(bolts
to left rear exhaust manifold stud; 1 required)
|
$
14.95 ea.
|
|
|
HF-M
|
IGNITION
WIRE BRACKET - All Big Blocks (1
- bolts under right side head bolt between cylinder #2 & #4
spark plug. Holds #4 & #6 cylinder ignition wires. 1 - bolts
under left side head bolt between cylinder #1 & #3 spark plug.
Holds #5 & #7 cylinder ignition wires. 2 required)
*MOST OFTEN MISSED & MOST IMPORTANT!
|
$
14.95 ea.
|
|
|
HF-O
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
under left front intake manifold gasket retaining rail screw; 1
required)
|
$
14.95 ea.
|
|
|
HF-Q
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
under right thermostat housing retaining screw; 1 required)
|
$
18.95 ea.
|
|
|
HF-R
|
IGNITION
WIRE BRACKET - All Big Blocks (1
- bolts to right front exhaust manifold stud. Holds all right side
wires. *some 67's used HF-P instead; 1 - bolts to left front exhaust
manifold stud. Holds all left side wires; 2 required)
|
$
14.95 ea.
|
1968
IGNITION WIRE BRACKETS
Brackets are correct gauge steel & rubber dipped where
applicable. Brackets may require minor bending or fitting to route
wires correctly. Brackets should be attached to, and painted with
engine.
|
|
|
HF-J
|
#8 CYLINDER
IGNITION WIRE BRACKET - All Big Blocks (bolts
to right rear exhaust manifold stud; 1 required)
|
$
14.00 ea.
|
|
|
HF-K
|
#7 CYLINDER
IGNITION WIRE BRACKET - Big Block C Body & applications where #7
cylinder ignition wire runs over valve cover
(bolts
to left rear exhaust manifold stud; 1 required)
|
$
14.00 ea.
|
|
|
HF-M
|
IGNITION
WIRE BRACKET - All Big Blocks (1
- bolts under right side head bolt between cylinder #2 & #4
spark plug. Holds #4 & #6 cylinder ignition wires. 1 - bolts
under left side head bolt between cylinder #1 & #3 spark plug.
Holds #5 & #7 cylinder ignition wires. 2 required)
*MOST OFTEN MISSED & MOST IMPORTANT!
|
$
14.00 ea.
|
|
|
HF-O
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
under left front intake manifold gasket retaining rail screw; 1
required)
|
$
14.50 ea.
|
|
|
HF-Q
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
under right thermostat housing retaining screw; 1 required)
|
$
18.50 ea.
|
|
|
HF-R
|
IGNITION
WIRE BRACKET - All Big Blocks (1
- bolts to right front exhaust manifold stud. Holds all right side
wires. 1 - bolts to left front exhaust manifold stud. Holds all left
side wires; 2 required)
|
$
14.50 ea.
|
|
|
HF-P
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
to right front exhaust manifold stud; fits some late 67's & all
68's; 1 required)
|
$
18.50 ea.
|
|
|
HF-L
|
IGNITION
WIRE BRACKET - All 68-69 Big Blocks (bolts
under HF-R & bends in front of head. Keeps wires away from
engine head heat; 1 required)
|
$
15.50 ea.
|
|
 |
HF-34068 |
IGNITION WIRE
BRACKET - All 68 340 engines (made
from correct gauge steel & thermoplastic coated as original;
keeps ignition wires from interfering with throttle cable &
trans kick down linkage) |
$ 21.95 ea. |
69-78
IGNITION WIRE BRACKETS
Brackets are correct gauge steel & rubber dipped where
applicable. Brackets may require minor bending or fitting to route
wires correctly. Brackets should be attached to, and painted with
engine.
|
|
|
HF-J
|
#8 CYLINDER
IGNITION WIRE BRACKET - All Big Blocks (bolts
to right rear exhaust manifold stud; 1 required)
|
$
14.00 ea.
|
|
|
HF-K
|
#7 CYLINDER
IGNITION WIRE BRACKET - Big Block C Body & applications where #7
cylinder ignition wire runs over valve cover
(bolts
to left rear exhaust manifold stud; 1 required)
|
$
14.00 ea.
|
|
|
HF-M
|
IGNITION
WIRE BRACKET - All Big Blocks (1
- bolts under right side head bolt between cylinder #2 & #4
spark plug. Holds #4 & #6 cylinder ignition wires. 1 - bolts
under left side head bolt between cylinder #1 & #3 spark plug.
Holds #5 & #7 cylinder ignition wires. 2 required)
*MOST OFTEN MISSED & MOST IMPORTANT!
|
$
14.00 ea.
|
|
|
HF-N
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
under left front intake manifold gasket retaining rail screw; 1
required)
|
$
12.00 ea.
|
|
|
HF-F
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
under right thermostat housing retaining screw; 1 required)
|
$
14.50 ea.
|
|
|
HF-H
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
to right front exhaust manifold stud; holds all right side wires; 1
required)
|
$
14.50 ea.
|
|
|
HF-G
|
IGNITION
WIRE BRACKET - All Big Blocks (bolts
to left front exhaust manifold stud. Holds all left side wires; 1
required)
|
$
14.50 ea.
|
|
|
HF-L
|
IGNITION
WIRE BRACKET - All 68-69 Big Blocks (bolts
under HF-R & bends in front of head. Keeps wires away from
engine head heat; 1 required)
|
$
9.50 ea.
|
|
|
HF-H1
|
IGNITION
WIRE BRACKET - All 72-78 Big Blocks (bolts
to right front exhaust manifold stud. Holds all right side wires; 1
required)
|
$
14.50 ea.
|
66-70 HEMI
IGNITION WIRE BRACKETS
|
|
|
HF-H2E
|
IGNITION WIRE BRACKET - 66-70 426
Hemi (center
wire separator bracket; used on all round air cleaner equipped cars
including 1970 Charger; bolts to upper coil bracket bolt and faces
forward. Bracket does NOT get painted with engine since it is
bolted in place with the coil bracket at time of assembly)
|
$ 39.95 ea.
|
|
|
HF-H3
|
IGNITION WIRE BRACKET - 66-70 426
Hemi (left
wire separator bracket; used on all round air cleaner equipped cars
including 1970 Charger. Bolts
to front throttle return spring bracket bolt and faces forward.
Painted with engine assembly)
|
$ 39.95 ea.
|
|
|
HF-H2L
|
IGNITION WIRE BRACKET - 69-71 426
Hemi (left wire
separator bracket; used on all oval air cleaner and SHAKER equipped
cars.
Bolts
to front throttle return spring bracket bolt and faces forward.
Painted with engine assembly)
|
$ 39.95 ea.
|
IGNITION
WIRE BRACKET KITS
|
HF-625SET |
HF-66SET |
HF-68SET |
HF-69SET |
HF-701SET |
HF-728SET |
|
|
HF-625SET |
1962-1965 BIG BLOCK
|
$ 89.95/set |
|
HF-66SET
|
1966-1967
BIG BLOCK (exc. A Body)
|
$
89.95/set
|
|
HF-68SET
|
1968
BIG BLOCK (exc. A Body)
|
$
89.95/set
|
|
HF-69SET
|
1969
BIG BLOCK (exc. A Body)
|
$
89.95/set
|
|
HF-701SET
|
1970-1971
BIG BLOCK
|
$
89.95/set
|
|
HF-728SET
|
1972-1978
BIG BLOCK
|
$
89.95/set
|
|
HF-WR36A |
HF-WR38A |
HF-WR49A |
|
IGNITION
WIRE BRACKET KITS
Complete kits come with every
bracket needed for Big Block A Body.
|
|
HF-WR36A
|
1967 A Body Big Block
|
$ 99.95/kit
|
|
HF-WR38A
|
1968 A Body Big Block
|
$ 99.95/kit
|
|
HF-WR49A
|
1969 A Body Big Block
|
$ 99.95/kit
|
|
